Walk Through Metal Detectors

Metal Detectors

Walk Through Metal Detector

Walk-through and handheld metal detectors are used to increase safety and security. Today these metal detectors are used not only at airports but in office buildings, theaters, and schools.  These multi-zone metal detectors are designed to keep you safe from the threat of metal weapons.

The metal detector works by generating a short pulse induction magnetic field across the opening. If a metal object passes through the detector, it creates an echo pulse that can be detected by the electronic circuits.

The latest walk-through detectors include multiple detection zones, so you can identify where the metal object is located. For example, a single zone walk-through detector only indicates that metal was detected. A two-zone detector can indicate if the metal is on the right or left side.  The more advanced detection systems can pinpoint the location with greater accuracy. For example, it can determine if there is a gun located at the ankle or belt.

A hand-held detector is also available.

Models

The following walkthrough detectors provide from 6 to 33 overlapping detection zones. You can select models with different adjustments, display, remote control and one model with TCP/IP communication.

Walk Through Metal Detctors
Walk Through Metal Detectors
TVIP118 TVIP318 TVIP433
6 overlapping zones 18 overlapping zones Up to 33 overlapping zones
NA NA Program modes available

· 1-zone

· 6-zone

· 11-zone

· 33-zone

Sensitivity adjustable in 100 increments Sensitivity adjustable in 255 increments Sensitivity adjustable in 300 increments
NADisplay: 5.7 inch (14.5 cm) Display: 5.7 inch (14.5 cm)
NA NAIP65 Weatherproof
NA NA Optional coaster wheelset available for portability
NA Infrared remote control Infrared remote control
NA NA TCP/IP Communication

Common features:

  • No need for manual calibration. The unit runs self-diagnostics and re-calibrates with each power-on
  • Modular design makes parts replacement and maintenance simple and easy.
  • Easy assembly: 2 pieces, cables, and 8 screws
  • 4-8 hours backup battery (optional for models TVIP318 and TVIP433. Not available with TVIP118)
  • Automatically counts people and alarms
  • Secure operation. Only authorized personnel can access the control panel.
  • Sound & LED alarms located on both sides clearly indicate precisely where metal is detected.
  • Completely safe to operate and walkthrough. Harmless to a heart pacemaker, pregnant women, magnetic storage media, etc.

Common Specifications

SpecValue
Power Supply85-264V AC
Working temperature4 F to 122 F (-20° to +50°)
Working Frequency4-8 kHz
Standard External Size87(H) x 32(W) x 23(D) inches (2200(H) x 800(W) x 580(D) millimeters)
Standard Internal Size79(H) x 28(W) x 20(D) inches (2010(H) X 700(W)X 500(D) millimeters)
Gross Weight155 lbs (70 kg)

Installation and setup

The metal detectors are all easy to install and set up. The units include easy to follow instructions. The units run automatic calibration each time the unit is powered on so manual calibration is not required.

Resources

Articles:

To learn more, take a look at our article “How Walk-Through Metal Detectors Work“.

How Technology Can Help in Active Shooter Situations, provides an overview of the technology that can be used.

Video:

Technology Provides Increased Security Describes when to use the different security technology including IP cameras, walk-through metal detectors, door access control, intercoms, and campus paging.

How Walk-Through Metal Detectors Work, describes the basic physics behind the product.

Technical Support

Kintronics is a resource for engineering and integration of all your security projects. We can design your complete system so don’t hesitate to contact us for assistance.

After purchasing your system, we make sure that it works exactly the way you expect. You can contact us for help with your installation and any technical support you may need.


We provide technical support and warranty support. Contact us at 1-800-431-1658 in the USA or 914-944-3425 everywhere else, or use our contact form.
