Samsung Hanwha Q Series IP Cameras

Q-Series-dome-bullet-IP-CamerasThese new cameras feature the ability to support the latest H.265 compression, which saves bandwidth and storage.  The family includes an affordable set of dome and bullet cameras that include 2-Megapixel and 4-Megapixel cameras.  The 4-Megapixels models include remote zoom and focus lens, yet are very inexpensive.

The cameras also provide WDR, and video analytics that includes motion detection, tampering and defocus detection.  This set of cameras provides the best cost-performance available.

There are indoor and outdoor vandal resistant cameras to choose from.  They all include IR-illumination.  Here are some of the models available.

Dome and Bullet IP Camera Specification and Comparison Table

MODEL RESOLUTION LENS and LIGHT SENSITIVITY
q-series-domesQND-6010R/6020R/6030R (Indoor)
QNV-6010R/6020R/6030R (Outdoor)
2-MP, 1920 x 1080 Lens: 2.8mm fixed (QNV-6010R), 3.6mm fixed (QNV-6020R), 6mm fixed (QNV-6030R)

Color : 0.15Lux, B/W : 0 Lux (IR LED on)
WDR: 120 dB

With Variable Lens

QND-6070R (Indoor)
QNV-6070R (Outdoor)

2-MP, 1920 x 1080 Lens: 2.8 ~ 12mm (4.3x) manual. H : 103.8˚ ~ 32.4˚ / V 53.7˚ ~ 18.4˚ / D 121.9˚ ~ 37.1˚
Manual focusColor : 0.095Lux (30IRE), B/W : 0 Lux (IR LED on)WDR: 120 dB
QND-7010R/7020R/7030R (Indoor)
QNV-7010R/7020R/7030R (Outdoor)
4-MP, 2592 x 1520 Lens: 2.8mm fixed (QNV-7010R), 3.6mm fixed (QNV-7020R), 6mm fixed (QNV-7030R

Color : 0.5Lux (QNV-7010R), 0.4Lux (QNV-7020R), 0.3Lux (QNV-7030R)
B/W : 0Lux (IR LED on)
WDR: 120 dB

With variable zoom lens and remote focus

QND-7084R (Indoor)
QNV-7084R (Outdoor)

4-MP, 2592 x 1520 Lens: 2.8 ~ 12mm (4.3x) motorized varifocal

Simple focus (Motorized V/F) / Manual, Remote control via network

Color : 0.095Lux (30IRE), B/W : 0 Lux (IR LED on)
WDR: 120 dB

Bullet IP Cameras

samsung-q-bullet-IP-cameraQNO-6010R/6020R/6030R
(Outdoor)

2-MP, 1920 x 1080 Lens: 2.8mm fixed (QNO-6010R), 3.6mm fixed (QNO-6020R), 6mm fixed (QNO-6030R)

Color : 0.15Lux, B/W : 0 Lux (IR LED on)
WDR: 120 dB

With Variable lens
QNO-6070R
2-MP, 1920 x 1080 Lens: 2.8 ~ 12mm (4.3x) manual

Color : 0.095Lux (30IRE), B/W : 0 Lux (IR LED on)
WDR: 120 dB

QNO-7010R/7020R/7030R
(Outdoor)
4-MP, 2592 x 1520 Lens: 2.8mm fixed (QNV-7010R), 3.6mm fixed (QNV-7020R), 6mm fixed (QNV-7030R)

Color : 0.5Lux (QNV-7010R), 0.4Lux (QNV-7020R), 0.3Lux (QNV-7030R)
B/W : 0Lux (IR LED on)

WDR: 60 dB

With variable remote zoom and focus lens

QNO-8080R
4-MP, 2592 x 1520 Lens : 2.8 ~ 12mm (4.3x) motorized varifocal
Simple focus (Motorized V/F) / Manual, Remote control via networkColor : 0.15Lux (30IRE), B/W : 0Lux (IR LED on)WDR: 120 dB
Common Specifications:
  • H.265, H.264, MJPEG codec supported, Multiple streaming
  • Motion detection, Tampering, Defocus detection
  • micro SD (128GB) memory slot, PoE / 12V DC
  • IR viewable length 30m, IP66, IK10
  • Hallway view support
  • LDC support (Lens Distortion Correction)
